Grass concealed hinge Tiomos 110° for applications with cleats, without damping - for screwing
- Grass hinge for pot applications 110°
- for stud applications
- Please select the version
€9.73*
Available in 25 days, delivery time 2 - 5 working days
Product number:
1005522
Product information "Grass concealed hinge Tiomos 110° for applications with cleats, without damping - for screwing"
Grass top hinge Tiomos 110° for frame applications
Product details
- Grass brand quality
- high-quality top hinge Tiomos 110°
- for frame applications (recessed)
- stable and robust furniture hinge for frame stop
- optional with or without integrated, 3-way adjustable damping in the hinge arm
- installation: door to body without tools (clip technology)
- with self-closing mechanism
- opening angle: 110°
- hole pattern: 42/11 mm
- material: steel
- surface: nickel-plated
Version: (please select)
- without damping - for screws
- without damping - tool-free
- with damping - for screws
- with damping - tool-free
Adjustment options:
- lateral adjustment from -2 to +2 mm
- depth adjustment from -2 to +3 mm
- height adjustment depending on mounting plate max. ±2.5 mm
Notes:
- Cross-mounting plate is not included - please order separately
- for flush front design of door and frame, use mounting plate with distance of 3 mm
Unit of quantity:
- per 1 piece of hinge
| EAN-Nr.: | 9010124636659 |
|---|---|
| Material: | steel |
